Double mast goods lift

Structure

Simplex Design Single Mast Structure Made From C" Channel Section Supported By Heavy-Duty Deep Grooved Guide Rollers Forks Lifted By Means Of 2 Nos. Double Chain & Pulley Design. Hydraulic Unit No. Vertical Mounted, Single Acting Honed Hydraulic Cylinder With Hard Chrome Plated Piston

Description

Suitable For Warehouses, Workshop In Automotive, Container Loading And Unloading.

Convenient Installations And Maintenance, Appearance, Safe And Convenient Operation

Specification

Model	specification
Model	specification	Capacity (KG)	500 TO 3000
Platform Size (W*L) (MM)	800 TO 6000
Mast	Double
Platform height(MM)	300 TO 2100
Lift Height (MM)	2000 TO 11000
Power Pack	Hydraulic AC
Lift/Lower Mode	AC Operated Hydraulic
Levels	G+2
Entry/Exit	Front and back
Lip	Optional at extra cost

Model	specification
Model	specification	Control Panel	CP at bottom & Top- stages
Control Panel - Auto Mode	Manual/Auto
AC Motor for Powerpack	Single phase / three phase
Hydraulics	Safety Valve, Pressure Relief Valve, Control Valve, Solenoid Valve, Pressure Gauge, Oil Level Indicator, Monoblock, Brether, Pump
Platform Doors, Side Shields	2 Side, 900 mm rails, one swing gate with mechanical lock
Doors on Door	2 nos - Sliding Grills G+2
Limit Switch	Provided for Lift cabin
Door Interlocks	Interlocks for Grill Door
